Resin cable gland series 1FC ISO110 N ° 16 N -A2S

Cable gland ADE 1FC

Name: Cable gland ADE 1FC
Brand: CAPRI
SKU: EAT0003

- ATEX and IECEX certifications
- Many other international certifications
- Prevents gas migration from the cable for ex d applications
- High Protective Protection Index IP66 / IP68 Personal and Practical:
- Quick visual identification thanks to the red deluge seal
- Wide allowable ambient temperature range
- Efficient and durable resin sealing on drivers

Garanties sécurité

(à modifier dans le module "Réassurance")

Politique retours

(à modifier dans le module "Réassurance")

Politique de livraison

(à modifier dans le module "Réassurance")

The ADE 1FC cable glander range allows for connecting an uninvored cable. ADE 1FC is available in nickel-plated brass or 316L stainless steel, with an ISO or NPT thread. This cable gland can be used for expanded antidoflage applications (ex d) or increased safety (ex e), in dust zones (ex tb) and also in mines (group I M2). Explusing sealing is ensured by an epoxy resin on cable conductors and a silicone ring on the outer sheath. A deluge protection seal reinforces the final sealing of the assembly, which offers a wide operating temperature range of -60 ° C to +80 ° C.

References Manufacturer: CAP010504V1, CAP010594V1, CAP010794V1, CAP011004V1, CAP011204V1, CAP011294V1, cap011404v1, cap011494v1, cap011604v1, cap011674v1, cap011694v1, cap011704v1, cap011794v1, cap011804v1, cap011894v1, cap011904v1, cap011994v1, cap012574v1, cap012594v1, cap012604v1, cap012694v1, cap012704v1, cap019004v1, cap019274v1, cap019294v1, cap019304v1, CAP019594V1, CAP019604V1, CAP019694V1, CAP019704V1, CAP019794V1, CAP019804V1, CAP019894V1, CAP019904V1, CAP019994V1

Ambiant temperature	-60°C to +80°C
Waterproofing protection (IP)	Ip66.ip68
Application / usage	ATEX zone
ATEX zone	Zone 1/2
Gas class	IIC
ATEX protection mode	Ex e (increased security)
Certificates	Atex.iecex
Material	316L Stainless Steel
Threading size	M16
Threading type	ISO
