ATEX SERIES EPC5 SERIES BASE
- IIC Group
- Zone 1, 2, 21, 22
- Aluminum alloy
- Ergonomic
- The cards can be used with industrial sockets
- Zone 1, 2, 21, 22
- Aluminum alloy
- Ergonomic
- The cards can be used with industrial sockets
Garanties sécurité
(à modifier dans le module "Réassurance")
Politique retours
(à modifier dans le module "Réassurance")
Politique de livraison
(à modifier dans le module "Réassurance")
The EPC power outlets, having a capacity of 63 to 125 A, particularly respond to the supply of welders, compressors, generators and large moving devices in general. The switch can only be closed when the switch is in the "open" position.
References Manufacturer: EPC1-1P125B, EPC1-1P63B, EPC1-1Q125B, EPC1-1Q63B, EPRC1-1P125B, EPRC1-1P63B, EPRC1-1Q125B, EPRC1-1Q63B
| Ambiant temperature | -20 ° C to + 50 ° C |
|---|---|
| Temperature class | T6 |
| Warranty | 2¨ |
| Waterproofing protection (IP) | Ip65 |
| Application / usage | ATEX zone |
| ATEX zone | Zone 1/2 |
| Gas class | IIC |
| Certificates | ATEX.IECEx.INMETRO |
| Frequency (Hz) | 50 / 60hz |
| Material | Aluminum |
| Certificat_atex-en_us | CESI 14 ATEX 017X |
| Certificat_iecex-en_us | These 11.0011x |
| Body colors | Ral7035 |
