Cable gland ADE 1F2 nickel-plated brass
Focusable safety:
- ATEX and IECEX certifications
- Many other international certifications
- Usable safely in zones 1, 2, 21 and 22
- High protection index IP66 / IP68
Performance and practical:
- Simple and fast installation
- Wide allowable ambient temperature range
- Proven reliability in severe industrial environments
- Available in the form of kits, with associated accessories
- ATEX and IECEX certifications
- Many other international certifications
- Usable safely in zones 1, 2, 21 and 22
- High protection index IP66 / IP68
Performance and practical:
- Simple and fast installation
- Wide allowable ambient temperature range
- Proven reliability in severe industrial environments
- Available in the form of kits, with associated accessories
(à modifier dans le module "Réassurance")
(à modifier dans le module "Réassurance")
(à modifier dans le module "Réassurance")
The ADE 1F2 cable glands connect a non-armed cable or shielded cable to an ex d, ex, ex, ex, ex, ex, ex, or ex P p unit in areas at risk of explosions. A wide range of threads is available, from M12 to M110 EN ISO or 1/4 '' to 4 '' in NPT, to cover all cable sizes.
References Manufacturer: CAP806404V1, CAP806404V1K2, CAP806404V1K3, CAP806404V1K4, CAP806409V1, CAP806409V1K1, CAP806409V1K2, CAP806504V1, CAP806504V1K1, CAP806504V1K2, CAP806504V1K3, CAP806504V1K4, CAP806509V1, CAP806509V1K1, CAP806509V1K3, CAP806594V1, CAP806594V1K1, CAP806594V1K2, CAP806594V1K3, CAP806599V1, CAP806599V1K1, CAP806599V1K3, CAP806604V1, CAP806604V1K1, CAP806604V1K3, CAP806604V1K4, CAP806609V1, CAP806609V1K1, CAP806609V1K2, CAP806609V1K3, CAP806664V1, CAP80664V1K1, CAP806664V1K3, CAP806664V1K4, CAP806669V1, cap806669v1k1, cap80669v1k2, cap80669v1k3, cap806674v1k1, cap806674v1k2, CAP806674V1K3, CAP806679V1, CAP806679V1K1, CAP806679V1K2, CAP806679V1K3, cap806694v1, cap806694v1k1, cap806694v1k3, cap806694v1k4, cap806699v1k1, CAP80699V1K2, CAP80699V1, CAP806704V1K1, CAP806704V1K2, CAP806704V1K4, CAP806709V1, CAP806709V1K1, CAP806709V1K3, CAP806774V1, CAP806774V1K1, CAP806774V1K2, CAP806774V1K3, CAP80674V1K4, CAP806779V1, CAP806779V1K2, CAP806779V1K3, CAP806794V1, CAP806794V1K1, CAP806794V1K3, CAP806794V1K4, CAP806799V1, CAP806799V1K1, CAP806799V1K2, CAP806804V1, CAP806804V1K1, CAP806804V1K3, CAP806804V1K4, cap806809v1, cap806809v1k2, cap80680v1k3, cap806894v1, cap806894v1k2, CAP806894V1K3, CAP806899V1, CAP806899V1K1, CAP806899V1K2, CAP806904V1, cap806904v1k1, CAP806904V1K3, CAP806904V1K4, CAP806909V1, CAP806909V1K2, CAP806909V1K3, CAP806994V1K1, CAP806994V1K3, CAP806994V1K4, CAP806999V1, CAP806999V1K1, CAP806999V1K3, CAP807004V1, CAP807004V1K1, CAP807004V1K3, CAP807009V1, CAP807009V1, CAP807009V1K2, CAP807009V1K3, CAP807084V1, CAP807084V1K1, CAP807084V1K2, CAP807084V1K4, CAP807089V1, CAP807089V1K2, CAP807089V1K3, CAP807094V1, CAP807094V1K2, CAP807094V1K3, CAP807094V1K4, CAP807099V1, CAP807099V1K1, CAP807099K2, CAP807204V1, CAP807204V1K1, CAP807204V1K2, CAP807204V1K4, CAP807209V1, CAP807209V1K1, CAP807209V1K3, CAP807294V1, CAP807294V1K1, CAP807294V1K2, CAP807294V1K3, CAP807299V1, CAP807299V1K1, CAP807299V1K2, CAP807304V1, CAP8079V1K2, CAP807304V1, CAP807304V1K1, CAP807304V1K2, CAP807304V1K4, CAP807309V1, CAP807309V1K1, CAP807309V1K2, CAP807309V1K3, CAP807504V1, CAP807504V1K2, CAP807504V1K3, CAP807504V1K4, CAP807509V1, CAP807509V1K1, CAP807509V1K2, CAP807594V1, CAP807594V1K1, CAP807594V1K2, CAP807594V1K3, CAP807594V1K4, CAP807599V1, CAP807599V1K2, CAP807599V1K3, CAP807604V1, CAP807604V1K1, CAP807604V1K2, CAP807604V1K4, CAP807609V1, CAP807609V1K1, CAP807609V1K2, CAP807609V1K3, CAP807704V1, CAP807704V1K1, CAP807704V1K3, CAP807709V1, CAP807709V1K1, CAP807709V1K2, CAP807709V1K3, CAP808404V1, CAP808404V1K2, CAP808404V1K3, CAP808404V1, CAP808409V1, CAP808409V1K1, CAP808409V1K3, CAP808504V1, CAP808504V1K2, CAP808504V1K3, CAP808509V1, CAP808509V1, CAP808509V1K2, CAP808594V1, CAP808594V1K1, CAP808594V1K2, CAP808594V1K4, CAP808599V1, CAP808599V1K2, CAP808599V1K3, CAP808604V1, CAP808604V1K2, CAP808604V1K3, CAP808609V1, CAP808609V1K1, CAP808609V1K2, CAP808609V1K3, CAP808664V1K1, CAP808664V1K2, CAP808664V1K3, CAP808664V1K4, CAP808669V1, CAP80869V1K1, CAP808669V1K3, CAP808674V1, CAP808674V1K1, CAP808674V1K2, CAP808674V1K4, CAP808679V1, CAP808679V1K1, CAP808679V1K2, CAP808694V1, CAP808694V1K1, CAP808694V1K2, CAP808694V1K3, CAP808694V1K4, CAP808699V1K1, CAP808699V1K3, CAP808704V1, CAP808704V1K1, CAP808704V1K2, CAP808704V1K4, CAP808709V1, CAP808709V1K1, CAP808709V1K3, CAP808774V1, CAP808774V1K1, CAP80874V1K2, CAP808774V1K4, CAP808779V1, CAP808779V1K1, CAP80879V1K2, CAP80879V1, CAP808794V1K1, CAP808794V1K2, CAP808794V1K3, CAP808799V1, CAP808799V1K1, CAP808799V1K3, CAP808804V1, cap808804v1k1, CAP808804V1K3, CAP808804V1K4, CAP808809V1, CAP808809V1K2, CAP808809V1K2, CAP808809V1K3, CAP808894V1, CAP808894V1K2, CAP80894V1K3, CAP808894V1K4, CAP808899V1, CAP80899V1K1, CAP80899V1K3, CAP808904V1, CAP808904V1K1, CAP808904V1K3, CAP808909V1, CAP808909V1K1, CAP808909V1K3, CAP808994V1, CAP808994V1K1, cap808994v1k2, CAP808994V1K4, CAP808999V1, CAP808999V1K1, CAP808999V1K3, CAP809004V1, CAP809004V1K1, CAP809004V1K3, CAP809004V1K4, CAP809009V1, CAP809009V1K1, CAP809009V1K2, CAP809094V1, CAP809094V1K1, CAP809094V1K3, CAP809094V1K4, CAP8099V1, CAP8099V1K2, CAP8099V1K3, CAP809204V1, CAP809204V1K1, CAP809204V1K2, CAP809204V1K3, CAP809204V1K4, CAP809209V1, CAP809209V1K2, CAP809209V1K3, CAP809294V1, CAP809294V1K1, CAP809294V1K2, CAP809294V1K3, CAP809299V1, CAP809299V1K1, CAP809299V1K2, CAP809299V1K3, CAP809404V1, CAP809404V1K1, CAP809404V1K3, CAP809404V1K4, CAP809409V1, CAP809409V1K1, CAP809409V1K2, CAP809409V1K3, CAP809494V1K1, CAP809494V1K2, CAP809494V1K3, CAP8094949K4, CAP809499V1K1, CAP809499V1K2, CAP809504V1, CAP809504V1K1, CAP809504V1K2, CAP809504V1K4, CAP809509V1, CAP809509V1K1, CAP809509V1K2, CAP809509V1K3, CAP809594V1, CAP809594V1K1, CAP809594V1K3, CAP809594V1K4, CAP809599V1, CAP809599V1K1, cap809599v1k2, CAP809604V1, CAP809604V1K1, CAP809604V1K2, CAP809604V1K3, CAP809604V1K4, CAP809609V1, CAP809609V1K1, CAP809609V1K3, CAP809704V1, CAP809704V1K1, CAP809704V1K2, CAP809704V1K3, CAP809709V1, CAP809709V1K1, CAP809709V1K3
Ambiant temperature | -60°C to +140°C |
---|---|
Protection étanchéité (IP) | IP66.IP68 |
Application/Usage | Zone ATEX |
Zone ATEX | Zone 1/2 |
Classe de gaz | IIC |
Mode de protection ATEX | Ex d (antidéflagrant) |
Certificats | ATEX.IECEx |
Matière | Laiton nickelé |
Certificat_ATEX-fr_FR | INERIS 12 ATEX 0032X |
Certificat_IECEx-fr_FR | IECEx INE 12.0025X |
Taille de filetage | M12 |
Couleurs corps | Gris métallisé |
Cable type | non armé |
Type de filetage | ISO |
Reference EAT0500
