The Spartan Linear range is designed for new facilities in ATEX zone or to modernize existing fluorescent facilities that require high performance and reliable white lighting. Using LED LED technology, the WL84 Linear is globally certified for all zone 2. Applications. The overall dimensions, mounting centers and cable glands are compatible with 2x18W common fluorescents, with a luminous flow and A distribution of light also offering a direct replacement. The CoolXtrude ™ Thermal Management Technology provides a life of 10 years and more while providing a luminous flux up to 3,524 lumens delivered. All Spartan luminaires come with a 5 year warranty at the forefront of the industry.
References Manufacturer: SPZ-WL84-G, SPZ-WL84-EMX25-G
- Brand
- RAYTEC
- Reference
- RTC0019
- ATEX zone
- Zone 2/22
- Ambiant temperature
- -40 ° to + 60 ° C
- Temperature class
- T4
- Warranty
- 5 year warranty (s)
- Feed
- 110-254V AC
- Waterproofing protection (IP)
- Ip66.ip67
- Application / usage
- ATEX zone
- Gas class
- IIC
- Certificates
- ATEX.CE.CERTIF_ABS.CERTIF_UKCA.IECEx
- Frequency (Hz)
- 50 / 60hz
- Certificat_atex-en_us
- Cml15atex4138
- Certificat_iecex-en_us
- IEC EX CML15.0068
- Body colors
- Silver (RAL 9006)
- Light source
- LED
- Color temperature
- 6500k
- Power
- 24w
- Light power
- 3524lm
- Shock resistance index
- Ik10
