ATEX SERIES SETUP SERIES EX RC SI M30
- IP67
- Ex 1 and 21 zones
- Metal housing
- Reed contacts, coded
- Front actuation
- Switching distance up to 10 mm
- Ex 1 and 21 zones
- Metal housing
- Reed contacts, coded
- Front actuation
- Switching distance up to 10 mm
Garanties sécurité
(à modifier dans le module "Réassurance")
Politique retours
(à modifier dans le module "Réassurance")
Politique de livraison
(à modifier dans le module "Réassurance")
The ex officous safety sensor if M30 1Ö / 1S - LED - 10m of Steute is a contactless device designed to ensure the safety of machines in industrial explosion industrial environments.
References Manufacturer: 1181148,1183059,1182420,1179392,117928,1178328,1178296,1179281,1186818,119928,118 9004,1188437,1185005,1188556,1186768,1182512,1182129,1188598,1189364,1189362,1189363
| Ambiant temperature | -20°C to +70°C |
|---|---|
| Temperature class | T6 |
| Warranty | 2¨ |
| Feed | 24V DC |
| Waterproofing protection (IP) | Ip67 |
| Application / usage | ATEX zone |
| ATEX zone | Zone 1/2 |
| Gas class | IIC |
| ATEX protection mode | Ex e (increased security) |
| Certificates | Atex.iecex |
| Material | Nickel-plated brass |
| Certificat_atex-en_us | PTB 05 ATEX 2024 x |
| Certificat_iecex-en_us | IECEX PTB 07.0008 x |
| Body colors | Gray metallic |
