Safety sensor ATEX Series EX RC SI 56
- Ex 1 and 21 zones
- IP67
- Plastic case
- Long life
- Reed contacts, coded
- Front actuation
- Switching distance up to 6 mm
- IP67
- Plastic case
- Long life
- Reed contacts, coded
- Front actuation
- Switching distance up to 6 mm
Garanties sécurité
(à modifier dans le module "Réassurance")
Politique retours
(à modifier dans le module "Réassurance")
Politique de livraison
(à modifier dans le module "Réassurance")
The ex officous safety sensor if 56 1000 / 1S - 10m is a device designed to ensure secure monitoring of removable, pivoting or sliding guards in industrial explosion environments.
References Manufacturer: 1185923,1189255,1182965,1182510,1184598,1190301,1189265,1184827,1189271, 1184434,1189262,1181390,1183009,1184620,1187207,1189273,1183978,1185181
| Ambiant temperature | -20°C to +70°C |
|---|---|
| Temperature class | T6 |
| Warranty | 2¨ |
| Feed | 24V DC |
| Waterproofing protection (IP) | Ip67 |
| Application / usage | ATEX zone |
| ATEX zone | Zone 1/2 |
| Gas class | IIC |
| ATEX protection mode | Ex e (increased security) |
| Certificates | Atex.iecex |
| Material | Plastic |
| Certificat_atex-en_us | PTB 08 ATEX 2027 x |
| Certificat_iecex-en_us | IECEX PTB 08.0042 x |
| Body colors | Black |
