Order station EFDC Anti-Detail Series
- IIC Group
- Zones 1, 2, 21, 22
- Aluminum alloy boxes, stainless steel or cast iron
- Category 2GD or M2
- Zones 1, 2, 21, 22
- Aluminum alloy boxes, stainless steel or cast iron
- Category 2GD or M2
Garanties sécurité
(à modifier dans le module "Réassurance")
Politique retours
(à modifier dans le module "Réassurance")
Politique de livraison
(à modifier dans le module "Réassurance")
The control and control units of the EFDC series are provided for the control and signaling of equipment, whether on board the machine or remote, and are used in the chemical, petrochemical and pharmaceutical industries and wherever the equipment explosions are needed. One of the features of these desks is the ability to apply up to four operators on their lid.
Manufacturer References: efdc-20, efdc-20/20, efdc-20/21, efdc-20/22, efdc-20/23, efdc-20/24, efdc-20/25, efdc -20 / 27, EFDC-21, EFDC-21/21, EFDC-21EM, EFDC-21EM, EFDC-21EmCV1, EFDC-21EmCV2, EFDC-21EMR, efdc-21mrv1, efdc-21Emrv2, efdc-21Emv, efdc-22, efdc-22/21, efdc-22/22, efdc-22/25, efdc-23, efdc-23/21, efdc-23/22, efdc-23/23, efdc-23/24, efdc-23/25, efdc-24, efdc-24/21, efdc-24/22, EFDC-24/24, EFDC-24/25, EFDC-25, EFDC-25/21, EFDC-25/25, EFDC-27, EFDC-27/21, EFDC-27/22, EFDC-27/23, EFDC-27/24, EFDC-27/25, EFDC-27/27, EFDC-28, EFDC-28/20, EFDC-28/21, EFDC-28/22, EFDC-28/23, EFDC-28/24, EFDC-28/25, EFDC-28/27, EFDC-28/28, EFDC-29, EFDC-29/20, EFDC-29/21, EFDC-29/22, EFDC-29/23, EFDC-29/24, EFDC-29/25, EFDC-29/27, EFDC-29/28, EFDC-29/29, EFDC-30, EFDC-30/20, efdc-30/21, efdc-30/22, efdc-30/23, efdc-30/24, efdc-30/25, efdc-30/27, efdc-30/28 EFDC-30/29 efdc-30/30 efdc-31, efdc-31/20, efdc-31/21, efdc-31/22, efdc-31/23, efdc-31/24, EFDC-31/25, efdc-31/27, efdc-31/28, efdc-31/29, efdc-31/30, efdc-31/31, efdc-32, efdc-32/20, efdc-32/21, efdc-32/22, efdc-32/23, efdc-32/24, efdc-32/25, efdc-32/27, efdc-32/28, efdc-32/29, efdc-32/30, efdc-32/31, efdc-32/32, efdc-33, efdc-33/20, efdc-33/21, efdc-33/22, efdc-33/23, efdc-33/24, efdc-33/25, efdc-33/27, efdc-33/28, efdc-33/29, efdc-33/30, efdc-33/31, efdc-33/32, efdc-33/33, efdc-34, efdc-34/20, efdc-34/21, efdc-34/22, efdc-34/23, efdc-34/24, efdc-34/25, efdc-34/27, efdc-34/28, efdc-34/29, efdc-34/30, efdc-34/31, efdc-34/32, efdc-34/33, efdc-34/34
| Ambiant temperature | -20°C to +55°C |
|---|---|
| Temperature class | T6 |
| Warranty | 2¨ |
| Application / usage | Zone ATEX |
| ATEX zone | Zone 1/2 |
| Gas class | IIC |
| ATEX protection mode | Ex d (antidéflagrant) |
| Certificates | ATEX.IECEx |
| Material | Aluminium |
| Certificat_atex-en_us | CESI 01 ATEX 092 X |
| Certificat_iecex-en_us | CES 17.0001X |
| Body colors | RAL7035 |
