MINICON SERIES 8595
- IP66
- Reliable switch-disconnector with lockable joystick clearly visible and indication of the switching position
- an integrated auxiliary contact for control and signaling purposes, optional extensible by ex e or ex auxiliary contacts pluggable and easy to install later
- Large operating temperature range
- High mechanical strength to shocks and impacts
- Perfect protection against the penetration of liquids and dust
- 3D data to download on the website
- Reliable switch-disconnector with lockable joystick clearly visible and indication of the switching position
- an integrated auxiliary contact for control and signaling purposes, optional extensible by ex e or ex auxiliary contacts pluggable and easy to install later
- Large operating temperature range
- High mechanical strength to shocks and impacts
- Perfect protection against the penetration of liquids and dust
- 3D data to download on the website
Garanties sécurité
(à modifier dans le module "Réassurance")
Politique retours
(à modifier dans le module "Réassurance")
Politique de livraison
(à modifier dans le module "Réassurance")
R. Stahl's 8579/31 Tickets for the 1/21 zone in version 4 and 5 poles offer full AC-3 switching power up to 63 A. The high degree of protection IP66 guarantees maximum protection against penetration of dust and water in all application positions. Self-cleaning lamellating contacts ensure optimum electrical contact and plugs can be easily connected and disconnected in the zero position. The switch-disconnector contributes to safety by a mechanical locking device thanks to its lockable joystick in position 0 and I.
References Manufacturer: 286541,286543,286530,286569,286554,286563,286566,286558, 286556,286562,28655,286565,28657,286561,286572,286573, 286567,286564,286570,286575,286568,286574,286577,28654 6,286547,286571,286544,286549,286550,286545,286553,28655 1,286552,286542,286548,286560,286559,286602,286603,2865 85,286576,286584,286580,286589,286579,286578,286582,2865 87,286588,286586,286600,286592,286590,286596,286598,286 599,286606,286605,286601,286608,286593,286583,286595,286 604,286607,286581,286591,286594,286597,286619,286614,28 6612,286609,286613,286610,286615,286611,286616,286618,28 6617,298963,298964,298965,298966,298967,298968,298969.2 98970,298971,298972,298973,298974,298951,298952,298953.2 98954,298955,298956,298957,298958,298959,298960,298961, 298962,298988,298989,298990,298991,298992,298993,298994, 298995,298996,298997,298998,298975,298976,298977,298978, 298979,298980,298981,298982,298983,298984,298985,298986
| Ambiant temperature | -40 ° C to + 75 ° C |
|---|---|
| Temperature class | T6 |
| Warranty | 2¨ |
| Feed | max. 500 V AC. 250V DC |
| Waterproofing protection (IP) | Ip66 |
| Application / usage | ATEX zone |
| ATEX zone | Zone 1/2 |
| Gas class | IIC |
| ATEX protection mode | Ex d (explosion) |
| Certificates | Atex.iecex |
| Frequency (Hz) | 50 / 60hz |
| Material | Nickel-plated brass |
| Threading size | M32 |
| Body colors | Black |
| Cable entry (s) | 1xm20 |
| Black (RAL9004) | 1 |
| Zone 1/21 | 1 |
| IIB | 1 |
| T5 | 1 |
| Reinforced polyester (GRP) | 1 |
| Ex of | 1 |
| 3xm32 | 1 |
| M25 | 1 |
