List of products by brand APOLLO FIRE
Flame Detector XP95 (IR3) - Mounted Based
- Reacts to stationary flames without flicker
- sensitive to low frequency infrared radiation emitted by flames during combustion
- Compact flame detector that integrates into Discovery or XP95 bases
- Buckle powered
- False alarms due to factors such as the flickering of sunlight are avoided through a combination of filters and signal processing techniques.
- sensitive to low frequency infrared radiation emitted by flames during combustion
- Compact flame detector that integrates into Discovery or XP95 bases
- Buckle powered
- False alarms due to factors such as the flickering of sunlight are avoided through a combination of filters and signal processing techniques.
The XP95 Flame Detector (IR3) with base mounting is designed for reliable fire detection through its three infrared sensors. This model allows quick identification of flames while minimizing false alarms, which makes it particularly suitable for industrial environments. Its base mount facilitates installation in various spaces, providing flexibility of use. Robust and powerful, the XP95 (IR3) detector provides effective protection against fire risks, ensuring the safety of people and property.
References Manufacturer: 55000-024APO
APO0012
Data sheet
- Ambiant temperature
- -40°C to +70°C
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip66
- Application / usage
- ATEX zone
- Certificates
- THIS
- Body colors
- White
- Type of detection
- Ir3
XPERT 7 base S.I.
- Xpert addressing
- Unidirectional adjustment
- Accepts only IS detectors
- Unidirectional adjustment
- Accepts only IS detectors
The Xpert 7 IS database is specially designed to accommodate only intrinsically safe (IS) certified equipment, ensuring that standard detectors can not be installed by error in a security system. This feature reinforces security by minimizing the risk of accidents in potentially hazardous environments. Each base is supplied with Xpert cards, facilitating installation and configuration. With its robust design and high technical specifications, the Xpert 7 IS base is a reliable choice for facilities requiring increased protection against the risk of explosion and fire.
References Manufacturer: 45681-215APO
APO0059
Data sheet
- Warranty
- 2¨
- Application / usage
- ATEX zone
- Certificates
- THIS
- Body colors
- White
Conventional Marine Manual Trigger - Exterior
- Suitable for weather-resistant applications
- Certified in 54-11
- "plug and play" terminal connections for faster wiring
- Continuity link for wiring test before commissioning
- Certified in 54-11
- "plug and play" terminal connections for faster wiring
- Continuity link for wiring test before commissioning
The manual call point is an essential device designed to manually trigger an alarm signal within a fire detection system. In case of emergency, its simple and fast use makes it possible to immediately warn the occupants of a building or an installation. Generally installed at strategic locations, it is easily accessible and visible, ensuring effective activation in crisis. This device contributes significantly to the safety of people and the protection of property by ensuring a quick response to fire incidents.
References Manufacturer: 55100-022mar
APO0055
Data sheet
- Ambiant temperature
- -25°C/+70°C
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip67
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- Red
- LED indicator
- 1¨
Marine Discovery heat detector [SIL2]
- Fire detection reliable in areas with a very wide temperature range from -40 ° C to + 70 ° C
- Five modes of operation adapted to a range of application temperatures
- Ideal for dirty or smoky environments in normal circumstances
- Drift compensation to ensure constant sensitivity
- Remote test functionality
- certified according to a wide range of marine approvals and approved by the EAC
- Five modes of operation adapted to a range of application temperatures
- Ideal for dirty or smoky environments in normal circumstances
- Drift compensation to ensure constant sensitivity
- Remote test functionality
- certified according to a wide range of marine approvals and approved by the EAC
The Discovery Marine Heat Detector is specially designed to withstand demanding maritime environments. Featuring a low airflow housing, it allows optimum flow, thus improving the accuracy of thermal detection. Thanks to its unique thermistor, the detector effectively monitors the temperature of the surrounding air, ensuring a quick response to the heat variations. Its robustness and reliability make it an ideal choice for ships and other maritime applications, ensuring increased safety against fire risks. Compact and easy to install, the Discovery detector is essential for the protection of people and equipment in critical environments.
References Manufacturer: 58000-400mar
APO0024
Data sheet
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip54
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
- LED indicator
- 1¨
Conventional Flame Detector (IR2) [SIL2]
- Class 1 sensitivity according to EN 54-10 detects a fire of 0.1 m2 to 25 m
- High immunity to optical interference
- selectable response speed
- Optical self-test
- Low energy consumption
- Compliant with the IP65 standard
- High immunity to optical interference
- selectable response speed
- Optical self-test
- Low energy consumption
- Compliant with the IP65 standard
The conventional flame detector (IR2) is specially designed to work in difficult environments, especially for indoor applications. It is equipped with two sensors that detect different infrared wavelengths, thus to differentiate the flames from spurious radiation sources. This advanced technology ensures accurate and reliable detection, involving the risks of false alarms. Perfect for industrial or commercial facilities, this detector offers increased fires against fire.
References Manufacturer: 55000-060APO
APO0014
Data sheet
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip65
- Application / usage
- ATEX zone
- Certificates
- THIS
- Body colors
- BLUE
- Type of detection
- Ir2
ATEX Orbis Optical Smoke Detector I.S.
- Reduces false alarms
- Recommended for early warning in case of fire in most regions
- Improved sensitivity to black smoke
- Compensation of slow sensitivity changes
- Algorithms for the reliability of alarms
- Recommended for early warning in case of fire in most regions
- Improved sensitivity to black smoke
- Compensation of slow sensitivity changes
- Algorithms for the reliability of alarms
The Orbis IS optical smoke detector is designed according to the principle of light diffusion, which makes it particularly effective for detecting slow or vein combustion fires. Its advanced technology allows early detection, ensuring a quick response in case of danger. Ideal for applications where this type of fire is likely, it ensures optimal safety while minimizing the risk of false alarms. This detector is therefore a judicious choice for environments requiring increased fire vigilance.
References Manufacturer: ORB-OP-52027-APO, ORB-OP-52028-APO
APO0065
Data sheet
- Ambiant temperature
- -40°C to +70°C
- Temperature class
- T4
- Warranty
- 2¨
- Feed
- 12-48V DC
- Waterproofing protection (IP)
- Ip23
- Application / usage
- ATEX zone
- ATEX zone
- Zone 1/2
- Gas class
- IIC
- Certificates
- Atex.iecex
- Material
- UV-resistant polycarbonate
- Certificat_atex-en_us
- Baseefa06atex0007x
- Certificat_iecex-en_us
- ECEX BAS 06.0002X
- Body colors
- White
- LED indicator
- 1¨
- Type of detection
- Smoke
- -40 ° to + 70 °
- 1
- Ip44
- 1
![DISCOVERY Navy multi-sensor detector (optics / heat) [SIL2] -A2s](https://www.a2s-atex.com/29-large_default/discovery-marine-optical-heat-multicast-detector-sil2-.jpg "DISCOVERY Navy multi-sensor detector (optics / heat) [SIL2] -A2s")
![DISCOVERY Navy multi-sensor detector (optics / heat) [SIL2] -A2s](https://www.a2s-atex.com/29-small_default/discovery-marine-optical-heat-multicast-detector-sil2-.jpg "DISCOVERY Navy multi-sensor detector (optics / heat) [SIL2] -A2s")
Discovery Marine (optical / heat) multicast detector [SIL2]
- Fire detection reliable in areas with a very wide temperature range from -40 ° C to + 70 ° C
- Five modes of operation for a personalized fire detection and improved management of false alarms
- Drift compensation to ensure constant sensitivity
- An excellent alternative to ionization detectors
- certified according to a wide range of marine approvals and approved by the EAC
- evaluated and certified for use in a safety function at the level SIL 2
- Five modes of operation for a personalized fire detection and improved management of false alarms
- Drift compensation to ensure constant sensitivity
- An excellent alternative to ionization detectors
- certified according to a wide range of marine approvals and approved by the EAC
- evaluated and certified for use in a safety function at the level SIL 2
The Discovery Marine multi-sensor detector is designed to provide reliable detection in marine environments. It integrates optical smoke sensors and a temperature sensor with thermistor, for providing a combined signal. This approach improves the management of false alarms, ensuring precise identification of emergency situations while reducing untimely triggers. Its robust and adapted to marine conditions ensures optimal performance, thus contributing to the safety of facilities and occupants.
References Manufacturer: 58000-700mar
APO0025
Data sheet
- Ambiant temperature
- -40 ° to + 70 °
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip44
- Application / usage
- Marine
- Certificates
- SIL
- Body colors
- White
- LED indicator
- 1¨
- Type of detection
- Smoke
Conventional Exd Flame Detector (IR2) - Explosion-proof [SIL2]
- Certified ATEX and IECEX: II2GD EX D IIC T4 GB EE TB IIICT135 ° C dB IP66 A21 (Zones 1, 21, 2 and 22)
- Selectable output options: two conventional wires, 4-20 mA, lockable or non-lockable, relay contacts - Fire / default, pre-alarm
- Class 1 sensitivity according to EN 54-10 detects a fire of 0.1 m2 to 25 m
- High immunity to optical interference
- selectable response speed
- Optical self-test
- Low energy consumption
- Selectable output options: two conventional wires, 4-20 mA, lockable or non-lockable, relay contacts - Fire / default, pre-alarm
- Class 1 sensitivity according to EN 54-10 detects a fire of 0.1 m2 to 25 m
- High immunity to optical interference
- selectable response speed
- Optical self-test
- Low energy consumption
The conventional ExD Flame Detector (IR2) is designed for potentially explosive environments, providing explosioning protection. Equipped with two infrared sensors, it effectively detects flames while minimizing false alarms due to spurious radiation sources. Its robust design and explosion envelope make it an ideal choice for industrial applications in risk areas, ensuring reliable monitoring and increased fires against fire. This detector ensures a quick response, essential for the protection of sensitive installations.
References Manufacturer: 55000-061APO
APO0015
Data sheet
- Temperature class
- T4
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip66
- Application / usage
- ATEX zone
- ATEX zone
- Zone 1/2
- Gas class
- IIC
- Certificates
- Atex.iecex
- Body colors
- Red
ATEX ORBIS heat detector I.S.
- Can be used for applications where smoke detectors are not suitable
- Ideal for dirty or smoky environments under normal conditions
- Reduction of misunderstandings of false alarms
- Increased reliability of detection
- Ideal for dirty or smoky environments under normal conditions
- Reduction of misunderstandings of false alarms
- Increased reliability of detection
The Orbis IS Heat Detector is an advanced security device designed to monitor the ambient temperature accurately. It uses a single network of thermistors that generates a voltage output proportional to the temperature of the surrounding air. This technology ensures a quick and reliable detection of thermal variations, which is essential to prevent fire risk. Suitable for various environments, including those at risk, the Orbis IS detector is easy to install and integrate into fire safety systems. Its constant performance and robustness make it a privileged choice to ensure the safety of facilities and people.
References Manufacturer: ORB-HT-51145-APO, ORB-HT-51146-APO, ORB-HT-51147-APO, ORB-HT-51148-APO, ORB-HT- 51149-APO, ORB-HT-51150-APO, ORB-HT-51151-APO, ORB-HT-51152-APO, ORB-HT-51153-APO, ORB-HT- 51154-APO, ORB-HT-51155-APO, ORB-HT-51156-APO, ORB-HT-51157-APO, ORB-HT-51158-APO
APO0066
Data sheet
- Ambiant temperature
- -40 ° to + 70 °
- Warranty
- 2¨
- Feed
- 12-48V DC
- Waterproofing protection (IP)
- Ip23
- Application / usage
- ATEX zone
- ATEX zone
- Zone 1/2
- Gas class
- IIC
- ATEX protection mode
- Ex i (intrinsic safety)
- Certificates
- ATEX
- Material
- UV-resistant polycarbonate
- Certificat_atex-en_us
- Bas06atex0007x
- Certificat_iecex-en_us
- Iecexbas05.0004
- Body colors
- White
- LED indicator
- 1¨
- Type of detection
- Smoke
65 series marine base
- detector lock mechanism
- Unidirectional adjustment
- Easy to wire
- Contains a ground connector
- does not contain any electrical parts
- Terminal for distance indicator
- Unidirectional adjustment
- Easy to wire
- Contains a ground connector
- does not contain any electrical parts
- Terminal for distance indicator
The 65 Series Marine Base is designed to meet the specific requirements of marine environments. Providing robustness and resistance to difficult conditions, it provides reliable integration of detectors and safety devices. This base is equipped with features that facilitate installation and maintenance, ensuring constant performance under moisture and corrosion conditions. Thanks to its ergonomic design, the 65 series marine base allows easy assembly, thus contributing to the safety of people and equipment on board ships and other maritime facilities. It is an ideal choice to strengthen protection against fire risks in a marine environment.
References Manufacturer: 45681-200mar
APO0029
Data sheet
- Warranty
- 2¨
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
Conventional Exd Flame Detector (IR3) - Explosion [SIL2]
- Certified ATEX and IECEX: II2GD EX D IIC T4 GB EX TB IIICT135 ° C dB IP66 A21 (Zones 1, 21, 2 and 22)
- Selectable output options: two conventional wires, 4-20 mA, lockable or non-lockable, relay contacts - Fire / default, pre-alarm
- Class 1 sensitivity according to EN 54-10 detects a fire of 0.1 m2 to 25 m
- High immunity to optical interference
- selectable response speed
- Optical self-test
- Low energy consumption
- Selectable output options: two conventional wires, 4-20 mA, lockable or non-lockable, relay contacts - Fire / default, pre-alarm
- Class 1 sensitivity according to EN 54-10 detects a fire of 0.1 m2 to 25 m
- High immunity to optical interference
- selectable response speed
- Optical self-test
- Low energy consumption
The conventional ExD Flame Detector (IR3) is specially designed for use in potentially explosive environments, with explosion protection. Featuring three infrared sensors, it allows precise and rapid detection of flames while potentially being the risk of false alarms caused by spurious radiation sources. Its robust and secure design makes it an ideal choice for industrial applications in high-risk areas. This detector ensures reliable monitoring and enhanced security, essential to protect sensitive fire facilities.
References Manufacturer: 55000-062APO
APO0016
Data sheet
- Temperature class
- T4
- Warranty
- 2¨
- Application / usage
- ATEX zone
- ATEX zone
- Zone 1/2
- Gas class
- IIC
- ATEX protection mode
- Ex d (explosion)
- Certificates
- Atex.iecex
- Body colors
- Red
- Type of detection
- Ir3
ATEX Orbis multi-sensor detector I.S.
- Reduces false alarms
- Fast and flamboyant fires sensitive
- Improved sensitivity to black smoke
- Compensation of slow sensitivity changes
- Algorithms for the reliability of alarms
- Fast and flamboyant fires sensitive
- Improved sensitivity to black smoke
- Compensation of slow sensitivity changes
- Algorithms for the reliability of alarms
The Orbis IS multi-sensor detector combines an advanced optical smoke detection technology with a heat sensor, providing optimal fire protection. Thanks to its fake alarm prevention system, it minimizes unnecessary triggers while ensuring rapid responsiveness in case of danger. This device is ideal for use in various environments, ensuring security and peace of mind.
References Manufacturer: ORB-OH-53027-APO, ORB-OH-53028-APO
APO0067
Data sheet
- Ambiant temperature
- -40 ° to + 70 °
- Temperature class
- T4
- Warranty
- 2¨
- Feed
- 24V DC
- Waterproofing protection (IP)
- Ip23
- Application / usage
- ATEX zone
- Gas class
- IIC
- ATEX protection mode
- Ex e (increased security)
- Certificates
- Atex.iecex
- Material
- UV-resistant polycarbonate
- Certificat_atex-en_us
- Bas06atex0007x
- Certificat_iecex-en_us
- Iecexbas05.0004
- Body colors
- White
- LED indicator
- 1¨
- Type of detection
- Smoke
Marine Xpert 7 base
- Xpert address Xpert address with all bases
- Lock function to prevent unauthorized removal of the detector
- Ideal for XP95 and Discovery detector ranges
- Marine Certified
- Exempt from EAC
- Lock function to prevent unauthorized removal of the detector
- Ideal for XP95 and Discovery detector ranges
- Marine Certified
- Exempt from EAC
The Xpert 7 Marine Base is specially designed for marine environments, offering exceptional robustness and reliability. Suitable for demanding maritime applications, this base allows easy integration of detectors and other safety devices. Its design resists moisture and corrosive conditions, ensuring optimal performance. In addition, it is equipped with features that facilitate installation and maintenance, thus contributing to the safety of people and equipment on board. The Xpert 7 database is an ideal choice to strengthen fire detection systems in a maritime environment.
References Manufacturer: 45681-210mar
APO0030
Data sheet
- Warranty
- 2¨
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
Conventional Flame Detector (UV / IR2) [SIL2]
- Class 1 sensitivity according to EN 54-10 detects a fire of 0.1 m2 to 25 m
- High immunity to optical interference
- selectable response speed
- Optical self-test
- Low energy consumption
- Compliant with the IP65 standard
- Power supply 14 to 30 VDC
- Operating temperature -10 ° C to + 55 ° C
- High immunity to optical interference
- selectable response speed
- Optical self-test
- Low energy consumption
- Compliant with the IP65 standard
- Power supply 14 to 30 VDC
- Operating temperature -10 ° C to + 55 ° C
The conventional flame detector (UV / IR2) combines two detection technologies: an ultraviolet sensor and an infrared sensor. This dual technology allows it to react quickly to the flames while distinguishing these sources of parasitic radiation. Designed for demanding environments, it offers reliable fire protection by minimizing the risk of false alarms. Ideal for industrial and commercial use, this detector ensures efficient and continuous monitoring of risk areas.
References Manufacturer: 55000-064APO
APO0017
Data sheet
- Warranty
- 2¨
- Application / usage
- ATEX zone
- Certificates
- THIS
- Body colors
- BLUE
- Type of detection
- Ir2
Base Timesaver Orbis I.S.
- Group terminals to facilitate the connection
- Two fixing centers
- LED alignment mark
- detector lock mechanism
- Two fixing centers
- LED alignment mark
- detector lock mechanism
The Orbis Is Timesaver base is designed to simplify the installation process, offering installers an open and accessible work area. Its shaped mounting holes allow quick and efficient assembly, including the time required for installation. This ergonomic design also facilitates the adjustment and alignment of the devices, which is essential in environments where each second counts. With the Orbis Is Timesaver base, professionals can carry out their facilities with increased efficiency, as safe by guaranteeing a perfect integration of the safety equipment involved.
References Manufacturer: ORB-MB-50018-APO
APO0068
Data sheet
- Warranty
- 2¨
- Application / usage
- ATEX zone
- Certificates
- Iecex
Marine insulator base [SIL2]
The marine insulating base [SIL2] is specially designed to ensure optimal security in demanding marine environments. Complies with SIL2 standards, it offers protection against electric defects and ensures effective insulation for fire detection systems. Its robust design resists moisture and corrosion, which makes it ideal for use on board ships and other maritime facilities. Easy to install and integrate with various safety devices, this base contributes to the safety of people and equipment, while ensuring reliable performance in difficult conditions.
References Manufacturer: 45681-211Mar
APO0031
Data sheet
- Warranty
- 2¨
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
Conventional Exd Flame Detector (UV / IR2) - Antidod [SIL2]
- ATEX Certification: II 2 GD
- CENELEC / IEC certified: EEX D - IIC T6- (Zones 1, 21, 2 and 22)
- Class 1 sensitivity according to EN 54-10 detects fires of 0.1 m2 to 25 m immunity with the highest optical interference
- selectable response speed
- Self-test of the remote control
- Low energy consumption
- CENELEC / IEC certified: EEX D - IIC T6- (Zones 1, 21, 2 and 22)
- Class 1 sensitivity according to EN 54-10 detects fires of 0.1 m2 to 25 m immunity with the highest optical interference
- selectable response speed
- Self-test of the remote control
- Low energy consumption
The ExD (UV / IR2) conventional flame detector is designed for potentially explosive environments, providing exploration protection. Thanks to its combination of ultraviolet and infrared sensors, it quickly detects flames while differentiating these parasitic radiation sources, minimizing false alarms. Its design guarantees robust and reliable performance in difficult conditions, making it an ideal choice for high-risk industrial applications. This detector ensures continuous monitoring and increased fires against fires.
References Manufacturer: 55000-065APO
APO0018
Data sheet
- Temperature class
- T6
- Warranty
- 2¨
- Application / usage
- ATEX zone
- ATEX zone
- Zone 1/2
- Gas class
- IIC
- Certificates
- Atex.iecex
- Body colors
- Red
- Type of detection
- ULTRAVIOLET
Basic adapter series 60 I.S. in Orbis I.S.
- Eliminates the need for reclaiming
The 60 Series Basic Adapter is a convenient device that allows you to connect IS series detectors to orbis systems. Designed to facilitate integration, this adapter ensures optimal compatibility while maintaining high performance. It is ideal for facilities where it is necessary to migrate to more recent technologies without replacing all existing equipment. Its robust design guarantees a simple and reliable installation, while offering an economical solution to modernize your detection system.
References Manufacturer: ORB-BA-50008-APO
APO0100
Data sheet
- Warranty
- 2¨
- Application / usage
- ATEX zone
- Gas class
- IIC
- Certificates
- Iecex
![Xpert 7 Marine Base - Insulation [SIL2] -A2s](https://www.a2s-atex.com/36-large_default/xpert-7-marine-base-7-insulating-sil2-.jpg "Xpert 7 Marine Base - Insulation [SIL2] -A2s")
![Xpert 7 Marine Base - Insulation [SIL2] -A2s](https://www.a2s-atex.com/36-small_default/xpert-7-marine-base-7-insulating-sil2-.jpg "Xpert 7 Marine Base - Insulation [SIL2] -A2s")
Xpert 7 Marine Base 7 - Insulating [SIL2]
- Up to 20 detectors or their equivalent load can be installed between insulating bases
- High brightness LED
- Detect connection short circuits
- Minimize disturbances due to short circuits
- High brightness LED
- Detect connection short circuits
- Minimize disturbances due to short circuits
The Xpert 7 Marine Base with isolation [SIL2] is designed to provide optimal protection in demanding maritime environments. This basis ensures efficient insulation, ensuring compliance with SIL2 safety standards, essential for critical applications. Its robust design and moisture resistance makes it ideal for use on ships and other maritime facilities. By facilitating the integration of detectors and safety devices, the Xpert 7 database contributes to reliable monitoring and the protection of people and property, while ensuring constant performance under difficult conditions.
References Manufacturer: 45681-286mar
APO0032
Data sheet
- Warranty
- 2¨
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
- LED indicator
- 1¨
XP95 Flame Detector (IR2)
- Sensitive to sparkling IR radiation
- detects through the films of oil, dust, water and ice
- Reacts to flickering flames, including those invisible to the naked eye
- Compatible with Discovery and XP95 protocols
- Remote optical self-test function
- 90 ° field of vision
- up to 40 m of coverage
- detects through the films of oil, dust, water and ice
- Reacts to flickering flames, including those invisible to the naked eye
- Compatible with Discovery and XP95 protocols
- Remote optical self-test function
- 90 ° field of vision
- up to 40 m of coverage
The XP95 Flame Detector (IR2) is designed to provide efficient fire detection through its two-infrared sensor technology. This model is able to quickly detect flames while minimizing false alarms, making it ideal for use in industrial and commercial environments. Its robust design ensures reliable performance in difficult conditions. Perfect for installations requiring constant monitoring of fire hazards, XP95 (IR2) guarantees increased protection for people and property.
References Manufacturer: 55000-280APO
APO0019
Data sheet
- Ambiant temperature
- -10 ° C to + 55 ° C
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip65
- Application / usage
- ATEX zone
- Certificates
- THIS
- Body colors
- BLUE
- Type of detection
- Ir2
Marine Optical Orbis Smoke Detector
- Reacts well to fast and flaming fires
- Reduction of false alarms
- accumulated reliability of detection
- the dust detection chamber and other suspended contaminants in the air to penetrate
- Works on a wide range of voltages at extreme temperatures
- LED flashing option
- Reduction of false alarms
- accumulated reliability of detection
- the dust detection chamber and other suspended contaminants in the air to penetrate
- Works on a wide range of voltages at extreme temperatures
- LED flashing option
The Orbis Marine optical smoke detector uses the light broadcast principle to effectively detect smoke. Its detection technology is innovative and improved compared to previous models, which significantly reduces false alarms. Designed for marine environments, this device offers increased reliability and rapid responsiveness, ensuring optimal fire protection. Perfect for ships and other maritime facilities, it combines performance and safety.
References Manufacturer: ORB-OP-42001-MAR, ORB-OP-42003-Mar
APO0047
Data sheet
- Ambiant temperature
- -40°C to +70°C
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip23
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
- Type of detection
- Smoke
Flame Detector XP95 EXD (IR2) - Explosion-proof
- Sensitive to sparkling IR radiation
- detects through the films of oil, dust, water and ice
- Reacts to flickering flames, including those invisible to the naked eye
- Compatible with Discovery and XP95 protocols
- Remote optical self-test function
- 90 ° field of vision
- up to 40 m of coverage
- Compliant with IP66
- detects through the films of oil, dust, water and ice
- Reacts to flickering flames, including those invisible to the naked eye
- Compatible with Discovery and XP95 protocols
- Remote optical self-test function
- 90 ° field of vision
- up to 40 m of coverage
- Compliant with IP66
The XP95 EXD Flame Detector (IR2) is specifically designed for potentially explosive environments, providing explosioning protection. Equipped with two infrared sensors, it allows fast and precise detection of flames while causing false alarms caused by spurious radiation sources. Its robust and secure design guarantees reliable performance in difficult conditions. Ideal for high-risk industrial applications, this detector ensures continuous monitoring and increased firefighting, protecting sensitive facilities and staff.
References Manufacturer: 55000-295APO
APO0020
Data sheet
- Ambiant temperature
- -10 ° C to + 55 ° C
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip66
- Application / usage
- ATEX zone
- ATEX protection mode
- Ex d (explosion)
- Certificates
- Iecex
- Body colors
- Red
- Type of detection
- Ir2
Orbis marine heat detector
- Can be used for applications where smoke detectors are not ideal for dirty or smoky environments under normal conditions
- The red flashing of the LED at startup confirms that the device works.
- SensAlert®, a flashing yellow LED indicates faulty operation
- FASTEST® only takes four seconds to test and confirm that the detectors work properly
- The red flashing of the LED at startup confirms that the device works.
- SensAlert®, a flashing yellow LED indicates faulty operation
- FASTEST® only takes four seconds to test and confirm that the detectors work properly
The Orbis heat detector is an innovative device that monitors ambient temperature through a single thermistor. This technology provides a voltage output proportional to the air temperature, ensuring accurate and reactive detection. Designed for use in various environments, the Orbis detector is ideal for applications where thermal monitoring is crucial. Its compact design and facility of installation make it a convenient choice for fire safety systems. Reliable and effective, it helps ensure a quick response in case of temperature variations, providing additional protection for people and property.
References Manufacturer: ORB-HT-41001-MAR, ORB-HT-41002-MAR, ORB-HT-41003-MAR, ORB-HT-41004-MAR, ORB-HT-41005-MAR, ORB-HT-41006-MAR, ORB-HT-41013-MAR, ORB-HT-41014-MAR, ORB-HT-41015-MAR, ORB-HT-41016-MAR, ORB-HT- 41017-Mar, ORB-HT-41018-Mar
APO0048
Data sheet
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip23
- Application / usage
- Marine
- Certificates
- Ce.certif_abs
- Body colors
- White
- LED indicator
- 1¨
Orbis Marine Multi-Current Detector
- Reacts well to fast combustion fires and flames
- Reduction of false alarms
- Increased reliability of detection
- The detection chamber prevents dust and other contaminants suspended in the air to penetrate
- Works on a wide range of voltages at extreme temperatures
- Flashing LED option
- Reduction of false alarms
- Increased reliability of detection
- The detection chamber prevents dust and other contaminants suspended in the air to penetrate
- Works on a wide range of voltages at extreme temperatures
- Flashing LED option
The Marine Orbis Multicaneur Detector combines an advanced technology for reducing false alarms, similar to that of the optical detector, with an additional heat detection element. This combination allows precise fire detection while minimizing untimely triggers. Designed for marine environments, this detector ensures reliable performance even in difficult conditions, providing optimal protection for sensitive areas. Its robust design and integrated technology guarantee rapid reactivity in the face of emergency situations, while strengthening occupant safety.
References Manufacturer: ORB-OH-43001-MAR, ORB-OH-43003-MAR
APO0050
Data sheet
- Ambiant temperature
- -40 ° to + 70 °
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip23
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
- LED indicator
- 1¨
- Type of detection
- Smoke
Marine Flame Detector (UV) 65 Series - Mounted Based
- Reacts to stationary flames without flicker
- Sensitive to UV rays emitted by flames during combustion
- Compact flame detector that fits into the 45681-200mar database
- Powered by zone
- Sensitive to UV rays emitted by flames during combustion
- Compact flame detector that fits into the 45681-200mar database
- Powered by zone
The 65 Series 65 (UV) flame detector is designed specifically for use in marine environments, offering quick detection of flames with its ultraviolet sensor. This model is easy to mount on a base, facilitating its installation. Thanks to its advanced technology, it is able to react quickly while minimizing false alarms, which is crucial for security on board. Ideal for ships and other marine facilities, this detector provides reliable fire protection, guaranteeing passenger and crew safety.
References Manufacturer: 55000-026mar
APO0051
Data sheet
- Ambiant temperature
- -40°C to +70°C
- Warranty
- 2¨
- Waterproofing protection (IP)
- Ip66
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
- Type of detection
- ULTRAVIOLET
Orbis Marine Timesaver base - Continuity Switch
- Group terminals to facilitate the connection
- Two fixing centers
- LED alignment mark Cable stripping guide
- detector lock mechanism
- Two fixing centers
- LED alignment mark Cable stripping guide
- detector lock mechanism
The Orbis Marine Timesaver base equipped with a continuity switch is designed to optimize the installation in marine environments. Its design offers an open work area with shaped mounting holes, allowing quick and easy mounting. The continuity switch ensures effective circuit monitoring, ensuring that the system is working properly and responds quickly in an emergency. Suitable for the requirements of maritime applications, this base combines robustness and reliability, contributing to the safety of people and equipment on board while simplifying installation and maintenance procedures.
References Manufacturer: ORB-MB-00001-MAR
APO0052
Data sheet
- Warranty
- 2¨
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
Orbis Marine Timesaver - Relais base
- Grouped terminals to facilitate wiring
- Multiple fixing centers
- LED alignment mark
- Cable stripping guide
- Continuity link for the zone wiring voltage test before commissioning
- detector lock mechanism
- Multiple fixing centers
- LED alignment mark
- Cable stripping guide
- Continuity link for the zone wiring voltage test before commissioning
- detector lock mechanism
The Marine Marine Timesaver base with relay is specially designed for marine environments, offering simplified and efficient installation. Its open work area and shaped mounting holes allow quick assembly, ideal for demanding maritime applications. Equipped with a relay, this base facilitates the control and activation of various safety devices, ensuring optimal integration in fire detection systems. Its robustness and design adapted to marine environments provide reliable performance, thus contributing to the safety of people and equipment on board.
References Manufacturer: ORB-RB-40004-Mar
APO0053
Data sheet
- Warranty
- 2¨
- Application / usage
- Marine
- Certificates
- THIS
- Body colors
- White
