DSP 15EExmNL (T) 25W Flameproof Loudspeaker

€0.00

Strong points:

  • Strong power 25W = 109 dB (1W/1m)
  • Waterproof protection IP66/67
  • Extreme temperature: -50°C / +60°C
  • Available in 2 models: 8 Ohms and 100V
  • Gas Group: IIB and IIC
  • Stainless steel fixing brackets

Customs Code:85182900
Country of origin :NO
Weight:2.8 kg
Stock:Available within 22 days*

Variant
Rupture de stock
  Garanties sécurité

(à modifier dans le module "Réassurance")

  Politique retours

(à modifier dans le module "Réassurance")

  Politique de livraison

(à modifier dans le module "Réassurance")



The DSP-15 anti-drug loudspeaker has an excellent bandwidth that allows to broadcast sound, voice or music. This product is available in 2 models: 8 Ohms and 100V. It is designed for use in explosive atmospheres zones 1, 2 (gas) and zone 21, 22 (pots).

ATEX-certified 25W polyamide pavilion speaker. This versatile model can be ordered with different transformers for more piquages and powers. The DSP-15 EExmN (T) is light and has M20 inputs at the back of the case for easy cable mounting. Additional terminal available for standard loop function. Also certified for the USA and Canada.

Do you need a light but powerful ATEX flag speaker in terms of sound coverage? Our new extended version of the DSP-15 EExmNT is an excellent choice when the required SPL needs to be high.

Certificate(s) ATEX
Protection against gas explosion Ex II 2G Ex d e mb IIB+H2/IIC T4 Gb
Protection against dust explosion Ex II 2D Ex tb IIIC T105°C
Material Antistatic polyamide / black
Ambiant temperature -50°C to +60°C
Version 8 Ohms or 100V
Power output up to 122 dB
Light power 25W
Sensitivity 109 db / 1W / 1m
Bandwidth 380 - 7000 Hz
Cable entries 2 x M20 with shutter caps
Mounting type Arm or arm articulated
Reference T406A009
