Bay Strong Power Spartan Hpby Series, Zone 21 -A2S

Bay LED Strong Power Spartan Hpby for Zone 21

Name: Bay LED Strong Power Spartan Hpby for Zone 21
Brand: RAYTEC
SKU: RTC0096

- IP66
- LED ultra long duration and high efficiency
- High performance output level 24278 lm
- BASE CONSOMATION (250W)
- Easy installation and maintenance
- Emergency lighting variant
- Large operating temperature -50 ° C to + 50 ° C
- 5 years warranty

Garanties sécurité

(à modifier dans le module "Réassurance")

Politique retours

(à modifier dans le module "Réassurance")

Politique de livraison

(à modifier dans le module "Réassurance")

The Spartan High Power Bay range is designed to illuminate large open spaces in dangerous environments. High Bay LED ATEX Available with a range of different powers from 20,000 to 30,000 lumens, the Spartan HPBY uses Raytec's proven LED LED technology to ensure a lifetime of more than 10 years. All Spartan luminaires benefit from a 5-year warranty, the best of the sector.

References Manufacturer: SPZ-HPBY30K-W-3030-Z21, SPZ-HPBY30K-W-6060-Z21, SPZ-HPBY30K-W-9090-Z21, SPZ-HPBY25K-W -3030-Z21, SPZ-HPBY25K-W-6060-Z21, SPZ-HPBY25K-W-9090-Z21, SPZ-HPBY20K-W-3030-Z21, SPZ- HPBY20K-W-6060-Z21, SPZ-HPBY20K-W-9090-Z21

Ambiant temperature	-50°C to +50°C
Temperature class	T4
Warranty	5 year warranty (s)
Feed	150-264v
Waterproofing protection (IP)	Ip66.ip67
Application / usage	ATEX zone
ATEX zone	Zone 1/21
Gas class	IIC
ATEX protection mode	Ex of
Certificates	ATEX.IECEx.UKCA
Frequency (Hz)	50 / 60hz
Material	Aluminum Marine Quality
Certificat_atex-en_us	CML 17ATEX1148
Certificat_iecex-en_us	IECEX CML 17.0074
Body colors	Silver (RAL 9006)
Light source	LED
Color temperature	5700k
Power	300w
Light power	29000lm
Cable entry (s)	2xm20
Ip66	1
110-254V AC	1
IIB	1
19423lm	1
250w	1
